? Modular design, ?exible customization
? Supports device parallel connection and multi-channel parallel connection
? Adopts advanced IGBT three-level technology architecture
? High-efficiency grid recovery capability, maximum grid recovery ef?ciency ≥ 92%
| Standard Version | Professional Version | ||
| Voltage | Range | 0-600V | 0-600V |
| Measurement and Control Accuracy | ≤±0.05%FS | ≤±0.03%FS | |
| Resolution | 1 mV | 1 mV | |
| Current | Range | 200A/300A/400A/600A | 200A/300A/400A/600A |
| Measurement and Control Accuracy | ≤±0.05%FS | ≤±0.03%FS | |
| Resolution | 1mA | 1mA | |
| Current Resp.Time | ≤10 ms(10%~90% FS) | ≤5 ms(10%~90% FS) | |
| Charge/discharge Conversion Time | ≤20 ms(10%~90% FS) | ≤10 ms(10%~90% FS) | |
| Minimum Data Logging interval | 1ms | 1ms | |
| Efficiency of the Whole Machine | ≥90% | ≥90% | |
